Description
- EFI or carbureted applications
- May be used in pulse modulated systems (PWM)
- Center-inlet design. Same fitment as Walbro GSS340(M), GSS307(M) and GSS294M pumps.
- Each pump individually tested
- For gasoline (use with E85 will reduce life expectancy)
- Integral check-valve
- Over-pressure safety bypass valve
MECHANICAL SPECS:
- Weight: 355 grams / 0.783 lbs
- Diameter: 38mm / 1.54″ O.D.
- Body: Black-plated steel with laser etching
- Inlet: 22mm / 0.866″ OD (non-tapered)
- Outlet: 8mm / 0.315″ (with barb)
- PRV Activation: 90PSI nominal
- Impeller design: Single-scroll hard-anodized aluminum turbine
ELECTRICAL SPECS:
- Recommended operating voltage: 13.5 volts DC
- Minimum operating voltage: 6 volts DC
- Max operating voltage: 18 volts DC
- Current draw @ 43.5PSI: 8 amps (13.5VDC)
- Current draw @ 58.0PSI: 10 amps (13.5VDC)
- Current draw @ 80.0PSI: 12 amps (13.5VDC)
